MIL-PRF-22/15C
TABLE I. Style RP05.
Nominal total
Maximum current
PIN 1/
Type designator 1/
resistance (ohms)
(amperes) 2/
M22/15-0001---
RP05---100KK
10
.707
M22/15-0002---
RP05---150KK
15
.583
M22/15-0003---
RP05---250KK
25
.447
M22/15-0004---
RP05---350KK
35
.374
M22/15-0005---
RP05---500KK
50
.316
M22/15-0006---
RP05---750KK
75
.264
M22/15-0007---
RP05---101KK
100
.223
M22/15-0008---
RP05---151KK
150
.182
M22/15-0009---
RP05---201KK
200
.158
M22/15-0010---
RP05---251KK
250
.141
M22/15-0011---
RP05---351KK
350
.118
M22/15-0012---
RP05---501KK
500
.100
M22/15-0013---
RP05---751KK
750
.082
M22/15-0014---
RP05---102KK
1,000 3/
.071
M22/15-0015---
RP05---152KK
1,500 3/
.056
M22/15-0016---
RP05---252KK
2,500 3/
.045
M22/15-0017---
RP05---352KK
3,500 3/
.037
M22/15-0018---
RP05---502KK
5,000 3/
.032
1/
The complete type designation and part number include symbols indicting
electrical off position from table II, style of shaft and type of mounting from
part number.)
2/
Not to be exceeded on any portion of the winding.
3/
Values based on the use of wire size smaller than 0.0025 inch but not less
than 0.0014 inch.
TABLE II. Electrical off position.
Symbol
Electrical off position
1
No electrical off position.
TABLE III. Style of shaft and type of mounting.
.125 inch diameter shaft
Style of
Symbol
Standard
shaft
Locking
bushing
S
Slotted
X
U
Slotted
X
4
