MIL-PRF-22/13C
TABLE I. Style RP50.
Nominal total
Maximum current
PIN 1/
Type designator 1/
(amperes) 2/
resistance (ohms)
M22/13-0001---
RP50---2R0KK
2.0
19.36
M22/13-0002---
RP50---2R5KK
2.5
17.32
M22/13-0003---
RP50---3R0KK
3.0
15.81
M22/13-0004---
RP50---4R0KK
4.0
13.69
M22/13-0005---
RP50---5R0KK
5.0
12.25
M22/13-0006---
RP50---7R5KK
7.5
10.00
M22/13-0007---
RP50---100KK
10
8.66
M22/13-0008---
RP50---120KK
12
7.90
M22/13-0009---
RP50---150KK
15
7.07
M22/13-0010---
RP50---250KK
25
5.48
M22/13-0011---
RP50---350KK
35
4.63
M22/13-0012---
RP50---500KK
50
3.87
M22/13-0013---
RP50---750KK
75
3.16
M22/13-0014---
RP50---101KK
100
2.74
M22/13-0015---
RP50---151KK
150
2.24
M22/13-0016---
RP50---201KK
200
1.94
M22/13-0017---
RP50---251KK
250
1.73
M22/13-0018---
RP50---351KK
350
1.46
M22/13-0019---
RP50---501KK
500
1.23
M22/13-0020---
RP50---751KK
750
1.00
M22/13-0021---
RP50---102KK
1,000
0.87
M22/13-0022---
RP50---122KK
1,200
0.79
M22/13-0023---
RP50---152KK
1,500
0.71
M22/13-0024---
RP50---202KK
2,000
0.61
M22/13-0025---
RP50---252KK
2,500
0.55
1/
The complete type designation and part number include symbols indicting
electrical off position from table II, style of shaft and type of mounting
example of part number.)
2/
Not to be exceeded on any portion of the winding.
TABLE II. Electrical off position.
Symbol
Electrical off position
1
No electrical off position.
2
Electrical off position at end of rotation of control knob in a counterclockwise direction.
3
Electrical off position at end of rotation of control knob in a clockwise direction.
TABLE III. Style of shaft and type of mounting.
0.375 inch diameter shaft
Symbol
Style of shaft
2 hole mounting
F
Flatted
X
4
