MIL-PRF-22/12D
TABLE I. Style RP45.
Nominal total
Maximum current
PIN 1/
Type designator 1/
resistance
(amperes) 2/
(ohms)
M22/12-0001---
RP45---2R0KK
2.0
15.81
M22/12-0002---
RP45---2R5KK
2.5
14.14
M22/12-0003---
RP45---3R0KK
3.0
12.91
M22/12-0004---
RP45---4R0KK
4.0
11.18
M22/12-0005---
RP45---5R0KK
5.0
10.00
M22/12-0006---
RP45---7R5KK
7.5
8.16
M22/12-0007---
RP45---100KK
10
7.07
M22/12-0008---
RP45---120KK
12
6.46
M22/12-0009---
RP45---150KK
15
5.79
M22/12-0010---
RP45---250KK
25
4.47
M22/12-0011---
RP45---350KK
35
3.78
M22/12-0012---
RP45---500KK
50
3.16
M22/12-0013---
RP45---750KK
75
2.58
M22/12-0014---
RP45---101KK
100
2.24
M22/12-0015---
RP45---151KK
150
1.82
M22/12-0016---
RP45---201KK
200
1.58
M22/12-0017---
RP45---251KK
250
1.41
M22/12-0018---
RP45---351KK
350
1.20
M22/12-0019---
RP45---501KK
500
1.00
M22/12-0020---
RP45---751KK
750
0.82
M22/12-0021---
RP45---102KK
1,000
0.71
M22/12-0022---
RP45---152KK
1,500
0.58
M22/12-0023---
RP45---202KK
2,000
0.50
M22/12-0024---
RP45---252KK
2,500
0.45
1/
The complete type designation and part number include symbols indicting
electrical off position from table II, style of shaft and type of mounting
example of part number.)
2/
Not to be exceeded on any portion of the winding.
TABLE II. Electrical off position.
Symbol
Electrical off position
1
No electrical off position.
2
Electrical off position at end of rotation of control knob in a counterclockwise direction.
3
Electrical off position at end of rotation of control knob in a clockwise direction.
TABLE III. Style of shaft and type of mounting.
0.375 inch diameter shaft
Symbol
Style of shaft
2 hole mounting
F
Flatted
X
4
