MIL-PRF-22/10D
TABLE I. Style RP35.
Nominal total
Maximum current
PIN 1/
Type designator 1/
resistance
(amperes) 2/
(ohms)
M22/10-0001---
RP35---2R0KK
2.0
10.61
M22/10-0002---
RP35---2R5KK
2.5
9.49
M22/10-0003---
RP35---3R0KK
3.0
8.66
M22/10-0004---
RP35---4R0KK
4.0
7.50
M22/10-0005---
RP35---5R0KK
5.0
6.71
M22/10-0006---
RP35---7R5KK
7.5
5.48
M22/10-0007---
RP35---100KK
10
4.74
M22/10-0008---
RP35---120KK
12
4.33
M22/10-0009---
RP35---150KK
15
3.87
M22/10-0010---
RP35---250KK
25
3.00
M22/10-0011---
RP35---350KK
35
2.54
M22/10-0012---
RP35---500KK
50
2.12
M22/10-0013---
RP35---750KK
75
1.73
M22/10-0014---
RP35---101KK
100
1.50
M22/10-0015---
RP35---151KK
150
1.22
M22/10-0016---
RP35---201KK
200
1.06
M22/10-0017---
RP35---251KK
250
0.95
M22/10-0018---
RP35---351KK
350
0.80
M22/10-0019---
RP35---501KK
500
0.67
M22/10-0020---
RP35---751KK
750
0.55
M22/10-0021---
RP35---102KK
1,000
0.47
M22/10-0022---
RP35---122KK
1,200
0.43
M22/10-0023---
RP35---152KK
1,500
0.39
M22/10-0024---
RP35---202KK
2,000
0.33
M22/10-0025---
RP35---252KK
2,500
0.30
1/
The complete type designation and part number include symbols indicting
electrical off position from table II, style of shaft and type of mounting
example of part number.)
2/
Not to be exceeded on any portion of the winding.
TABLE II. Electrical off position.
Symbol
Electrical off position
1
No electrical off position.
2
Electrical off position at end of rotation of control knob in a counterclockwise direction.
3
Electrical off position at end of rotation of control knob in a clockwise direction.
TABLE III. Style of shaft and type of mounting.
0.375 inch diameter shaft
Symbol
Style of shaft
2 hole mounting
F
Flatted
X
4
