MIL-PRF-18546/2C
3.4 Resistance. The minimum and maximum nominal resistance values shall be as specified in
table III.
TABLE III. Minimum and maximum nominal resistance values.
Style
Resistance values (Ohms)
Minimum
Maximum
Characteristic
Characteristic
G
N
G 1/
N
RE77
0.05
1
29,400
14,700
RE80
0.10
1
35,700
17,400
1/ Based on use of 0.00175 inch nominal diameter wire.
4. VERIFICATION
4.1 Sampling and inspection. Sampling and inspection shall be in accordance with MIL-PRF-18546,
and as specified herein.
4.2 Terminal strength. The direct pull shall be as specified in table IV.
TABLE IV. Direct pull.
Style
Direct pull
Torque
(pounds)
(pounds-inches)
RE77
10 +0, -1/2
24
RE80
10 +0, -1/2
32
4.3 Dielectric withstanding voltage.
4.3.1 At atmospheric pressure. The magnitude of the test voltage shall be 4,500 volts.
4.3.2 At reduced barometric pressure. The magnitude of the test voltage shall be 1,000 volts.
4.4 Chassis dimensions. The chassis dimensions shall be as specified in table V.
TABLE V. Chassis dimensions. 1/
Style
Length, width, and height
Thickness
RE77
9X7X2
0.06
RE80
9X7X2
0.06
1/ All dimension are given in inches.
4
