MIL-PRF-12934/35C
mm
Inches
mm
Inches
mm
Inches
mm
Inches
.0003
0.008
.062
1.57
1.000
25.40
2.000
50.80
.001
0.03
.093
2.36
1.188
30.18
2.031
51.59
.031
0.79
.2497
6.342
1.875
47.63
4.281
108.74
Maximum starting and running torque
Maximum continuous
Power
Stop torque
First cup
Second Cup
Style
Turns
Working voltage
rating
(pound- inch)
(watts) 1/
(volts)
Starting
Running
Starting
Running
2RR2104
10
500
5.0
2.0
1.0
2.0
1.0
35
1/
When ten-turn units are ganged, all cups shall be 75% of rated wattage
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
FIGURE 1. Style 2RR2104
1.2.6 Function-conformity tolerance and resistance tolerance characteristics. The function-conformity tolerance
and resistance tolerance characteristic applicable to this specification is symbol L.
1.2.7 Resistance. The nominal total resistance values and nominal resolution applicable to this specification is as
follows:
20 kilohms (k).
First cup
20 kilohms (k).
Second cup
