\MIL-PRF-12934/30F
3. REQUIREMENTS
3.1 General. The requirements for acquiring the product described herein shall consist of this document and
3.2 Interface and physical dimensions. The resistors shall meet the interface and physical dimensions specified in
figure 1.
105 MAX
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
0.005
0.13
0.040
1.02
0.080
2.03
0.281
7.14
0.906
23.01
0.010
0.25
0.060
1.52
0.125
3.18
0.312
7.92
1.062
26.97
0.020
0.51
0.062
1.57
0.250
6.35
0.625
15.88
Maximum starting and running torque
Maximum
(ounce-inch)
continuous Power rating
Stop-torque
L
K
Style
Turns
working
(watts)
Ten-turn
Per each additional
(pound-inch)
(max)
(max)
1/
voltage
single cup
ten-turn cup
(volts)
Starting
Running
Starting
Running
1.219
0.968
RR3900
Five
500
1.5
.5
.4
.4
.3
3
(30.96)
(24.59)
1/
When five turn units are ganged, all cups will be 75% of rated wattage.
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
FIGURE 1. Style RR3900
