MIL-PRF-12934/20D
3. REQUIREMENTS
3.1 General. The requirements for acquiring the product described herein shall consist of this document and
3.2 Interface and physical dimensions. The resistors shall meet the interface and physical dimensions specified in
figure 1.
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
.0005
0.01
.010
0.25
.073
1.85
1.094
27.79
1.437
36.50
.0006
0.02
.031
0.79
.093
2.36
1.3125
33.32
1.468
37.29
.005
0.13
.062
1.57
.250
6.35
1.313
33.35
1.625
41.28
Maximum starting and running torque
Maximum
(ounce-inch)
Stop-
continuous Power rating
L
K
Torque
Style
Turns
working
(watts)
Ten-turn
Per each additional
(max)
(max)
(pound-inch)
1/
voltage
single cup
ten-turn cup
(volts)
Starting
Running
Starting
Running
2.250
2.000
RR1400
Ten
500
3.0
1.0
.7
.8
.6
8
(57.15)
(50.80)
1/
When ten turn units are ganged, all cups will be 75 percent of rated wattage.
NOTES:
1.
Dimensions are in inches.
2.
Metric equivalents are given for general information only.
Figure 1. Style RR1400
