MIL-PRF-12934/2D
1.2.2 Class and center tap. The class and center tap applicable to this specification are symbols 2, 3, 4, and 5.
1.2.3 Resistance temperature characteristic. The resistance temperature characteristic applicable to this
specification are symbols A to H, inclusive.
1.2.4 Rotational life characteristic. The rotational life characteristics applicable to this specification are symbols 7,
8, and 9. This potentiometer is capable of operations up to 100 rpm.
1.2.5 Function-conformity tolerance and resistance tolerance characteristics. The function-conformity tolerance
and resistance tolerance characteristic applicable to this specification are symbols G to L, inclusive and S to X,
Inclusive.
1.2.6 Resistance. The nominal total resistance values and nominal resolution applicable to this specification is in
accordance with table II.
TABLE II.
Nominal total resistance and
nominal resolution characteristics.
Nominal total
Nominal
resistance value
resolution
Ohms
Percent
100
0.32
200
0.27
500
0.20
1,000
0.17
2,000
0.15
5,000
0.11
10,000
0.10
20,000
0.09
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements documents cited in sections 3 and 4 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation (see 6.2).
DEPARTMENT OF DEFENSE SPECIFICATION
-
Resistors, Variable, Wirewound, Precision, General Specification for.
(Copies of these documents are available online at https://assist.daps.dla.mil/quicksearch/ or from the
Standardization Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA 19111-5094).
2.3 Order of precedence. In the event of a conflict between the text of this document and the references cited
herein (except for related specification sheets), the text of this document takes precedence. Nothing in this
document, however, supersedes applicable laws and regulations unless a specific exemption has been obtained.
2
