MIL-PRF-12934/19D
3. REQUIREMENTS
3.1 General. The requirements for acquiring the product described herein shall consist of this document and
3.2 Interface and physical dimensions. The resistors shall meet the interface and physical dimensions specified in
figure 1.
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
.0005
0.01
.010
0.25
.073
1.85
1.094
27.79
1.437
36.50
.0006
0.02
.031
0.79
.093
2.36
1.3125
33.32
1.468
37.29
.005
0.13
.062
1.57
.250
6.35
1.313
33.35
1.625
41.28
Maximum starting and running torque
Maximum
(ounce-inch)
continuous
Power rating
L
K
Style
Turns
working
(watts)
Single turn
Per each additional
(max)
(max)
1/
voltage
single cup
single-turn cup
(volts)
Starting
Running
Starting
Running
1.062
0.687
RR1300
Single
250
2.0
1.0
0.75
0.8
0.6
(26.97)
(17.46)
1/
When single turn units are ganged, the first cup will be full wattage rating, the remaining cups will be
75 percent of rated wattage.
NOTES:
1.
Dimensions are in inches.
2.
Metric equivalents are given for general information only.
FIGURE 1. Style RR1300
3
