A-A-55564/1B
Capacitance. The capacitance shall be as specified in table I.
O
O
Operating ambient temperature. The operating ambient temperature range shall be -55 C to +85 C.
O
O
Storage temperature. The storage temperature shall be -55 C to +125 C.
Marking. Varistors supplied to this CID shall be marked with the manufacturer's standard commercial
PIN.
Clamping voltage. The clamping voltage shall be as specified in table I.
Dimensions
Inches
Millimeters
Symbol
Notes
Min
Max
Min
Max
A
0.57
14.5
B
0.498
0.508
12.5
12.90
C
0.26
6.6
D
2.61
66.3
D1
1.32
33.5
G
0.248
0.260
6.30
6.60
3
H1
1.01
25.7
4
H2
1.12
28.4
4
H3
1.29
32.8
4
J
0.32
8.1
K
1.99
2.01
50.5
51.1
L
0.22
0.24
5.6
6.1
M
0.155
0.165
3.94
4.19
S
0.72
0.78
18.3
19.8
T
0.118
0.122
3.00
3.10
NOTES:
1. Dimensions are in millimeters.
2. Inch equivalents are given for general information only.
3. Tab is designed to fit .25 inch quick connect terminal.
4. H1 (130-150 V rms devices).
H2 (250-320 V rms devices).
H3 (420-660 V rms devices).
FIGURE 1. Case dimensions and configuration.
