[METRIC]
A-A-55562A
30 August 2001
SUPERSEDING
A-A-55562
13 February 1995
COMMERCIAL ITEM DESCRIPTION
RESISTOR, VOLTAGE SENSITIVE (VARISTOR, METAL OXIDE), CHIP
The General Services Administration has authorized the use of this
commercial item description (CID) for all federal agencies.
1. SCOPE. This CID covers the general requirements for a varistor. The varistor covered by this CID is intended for
commercial/industrial applications.
2. CLASSIFICATION. This CID uses a classification system which is included in the Part or Identification Number
(PIN) as shown in the following example (see 7.1).
AA55562
01
-001
C
|
|
|
|
|
|
|
|
|
|
|
|
Abbreviated
Applicable
Dash number
Termination finish
CID number
CID sheet
(see applicable
(see 3.2 and Table I)
(two digits)
CID sheet)
3. SALIENT CHARACTERISTICS
3.1 Interface and physical dimensions. The varistors supplied to this CID shall be as specified on the applicable
CID sheet.
3.2 Termination finish. The termination finish is identified by a single letter in accordance with table I.
TABLE I. Termination finish.
Code letter
Termination finish
C
Platinum/Palladium/Silver
(Pt/Pd/Ag)
P
Nickel barrier with Tin Alloy
Plated finish (Ni/Sn)
3.3 Ambient temperature. The ambient temperature shall be -55°C to +125°C.
3.4 Marking. Marking of individual varistors is not required but is permitted; however, each unit pack shall be
marked with the manufacturer's standard commercial PIN.
4. REGULATORY REQUIREMENTS. This section is not applicable to this CID.
Beneficial comments, recommendations, additions, deletions, clarifications, etc., and any data which may improve
this document should be sent to: Defense Supply Center, Columbus, ATTN: DSCC-VAT, P. O. Box 3990,
Columbus, OH 43216-5000, or telephone (614) 692-0553, or facsimile (FAX) (614) 692-6939.
AMSC N/A
FSC 5905
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
