A-A-55562/4A
L
W
D
E
3.20 +0.2 2.49 +0.2 1.70 max 0.71 max
mm
Inches
0.2
0.01
0.71
0.028
1.70
0.067
2.49
0.098
3.20
0.126
NOTES:
1. Dimensions are in millimeters. Inch-pound equivalents are given for information only.
2. The US government preferred system of measurement is the metric SI system. However, this item was
originally designed using inch-pound units of measurement. In the event of conflict between the metric and
inch-pound units, the inch-pound units shall take precedence.
Figure 1. Interface and physical dimensions, style 1210.
2
