[INCH-POUND]
A-A-55502D
22 May 2014
SUPERSEDING
A-A-55502C
12 October 2007
COMMERCIAL ITEM DESCRIPTION
RESISTOR, FIXED, ZERO OHM, 1/8 WATT
The General Services Administration has authorized the use of
this commercial item description (CID) for all federal agencies
1. SCOPE. This CID covers the general requirements for axial leaded zero ohm resistors. Resistors
covered by this CID are intended for commercial/industrial applications and are not to be used in military
systems needing stringent environmental and electrical requirements.
2. CLASSIFICATION/PART OR IDENTIFICATION NUMBER (PIN). This CID uses a classification
system which is included in the PIN as shown in the following example (see 7.1).
A-A-55502
CID Number
3. SALIENT CHARACTERISTICS.
3.1 Interface and physical dimensions. Resistors supplied to this CID shall be as specified herein (see
figure 1).
3.2 DC resistance. The resistance value shall not exceed 0.01 ohm.
3.3 Insulation resistance. The insulation resistance value of this resistor shall be 10,000 megohms
minimum.
3.4 Current rating. The current rating shall be 5 amperes maximum.
3.5 Dielectric withstanding voltage. The dielectric with standing voltage shall be 450 volts minimum.
*
3.6 Pure tin. The use of pure tin, as an underplate or final finish is prohibited both internally and
externally. Tin content of resistor components and solder shall not exceed 97 percent, by mass. Tin shall
be alloyed with a minimum of 3 percent lead, by mass.
3.7 Marking. Resistors supplied to this CID shall be marked with the manufacturer's (MFR's) standard
commercial PIN (NOTE: The part number marked on the unit pack shall be the CID PIN).
Beneficial comments, recommendations, additions, deletions, clarifications, etc., and any data that
may improve this document should be sent to: DLA Land and Maritime, ATTN: VAT, P.O. Box 3990,
Columbus, OH 43218-3990, or email Resistors@dla.mil. Since contact information can change, you
may want to verify the currency of the address information using the ASSIST Online database at
AMSC N/A
FSC 5905
