INCH-POUND
MIL-PRF-83401/5E
5 May 2006
SUPERSEDING
MIL-PRF-83401/5D
18 March 1996
PERFORMANCE SPECIFICATION SHEET
RESISTOR NETWORK, FIXED, FILM
STYLE RZ050, 8 PIN SIP
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the associated requirements for style RZ050, 8 pin single-in-line package
(SIP) resistor networks. This style is available in all characteristics and resistance tolerances of F, G, and J. This
specification has two product levels, a high reliability, 100 percent burn-in screened "M" part number level and
nonburn-in screened part number "C".
1.2 Part or Identifying Number (PIN). Resistor networks covered by this specification are identified by a PIN which
will consist of the basic number of this specification and a coded number. The PIN is in the following form:
100 percent burn-in screened network ("M" part number)
M8340105
H1002FC
|______
|
_
Associated specification number
Coded number
Nonburn-in screened network ("C" part number)
C8340105
H1002FC
|______
|
_
Associated specification number
Coded number
The coded number is derived in accordance with MIL-PRF-83401.
