INCH-POUND
MIL-PRF-83401/1H
5 May 2006
SUPERSEDING
MIL-PRF-83401/1G
18 March 1996
PERFORMANCE SPECIFICATION SHEET
RESISTOR NETWORK, FIXED, FILM,
STYLE RZ010, 14 PIN DIP
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the associated requirements for style RZ010, 14 pin dual-in-line package
(DIP) resistor networks. This style is available in all characteristics and resistance tolerances. This specification has
two product levels, a high reliability, 100 percent burn-in screened "M" part number and a nonburn-in screened part
number "C".
1.2 Part or Identifying Number (PIN). Resistor networks covered by this specification are identified by a PIN which
will consist of a basic number of this specification and a coded number. The PIN is in the following form:
100 percent burn-in screened network ("M" part number)
M8340101
H1002FA
|
_
|______
Associated specification number
Coded number
Nonburn-in screened network ("C" part number)
C8340101
H1002FA
|
_
|______
Associated specification number
Coded number
The coded number is derived in accordance with MIL-PRF-83401.
Comments, suggestions, or questions on this document should be addressed to: Defense Supply Center, Columbus
ATTN: DSCC-VAT, Post Office Box 3990, Columbus, OH 43218-3990, or emailed to resistor@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST Online
database at https://assist.daps.dla.mil.
AMSC N/A
FSC 5905
