INCH-POUND
MIL-PRF-12934/18E
25 August 2009
SUPERSEDING
MIL-PRf-12934/18D
1 February 1999
PERFORMANCE SPECIFICATION
RESISTORS, VARIABLE, WIREWOUND, PRECISION,
STYLE RR3500
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and MIL-PRF-12934.
1. SCOPE
1.1 Scope. This specification covers the requirements for style RR3500, variable, wire-wound, precision resistors.
1.2 Part or Identifying Number (PIN). Variable resistors covered by this specification must be identified by a PIN
which must be in the following form.
Single-section (cup) resistors
RR3500
A
2
A
7
J
103
⏐
⏐
⏐
⏐
⏐
⏐
⏐
⏐
⏐
⏐
⏐
⏐
⏐
⏐
Rotational life
Resistance
Style
Function
Class and
Resistance
Function conformity
characteristic
(1.2.6)
and shaft
center tap
temperature
tolerance and
(1.2.4)
length
(1.2.2)
characteristic
resistance
(1.2.3)
(1.2.1)
tolerance
characteristic
(1.2.5)
1.2.1 Function and shaft length. The function and shaft length applicable to this specification is identified by a
single symbol in accordance with table I.
TABLE I. Function and shaft length.
Shaft length tolerance
Symbol
Function
±0.03125 (.79) 1/
A
0.750 (19.05)
Linear
B
0.875 (22.23)
Linear
C
1.000 (25.40)
Linear
D
1.125 (28.58)
Linear
E
1.250 (31.75)
Linear
F
1.375 (34.93)
Linear
1/
Metric equivalents are in parentheses.
